Products
0.25kW 289rpm BLDC Hub Motor / EHUB180-70S1K02A1-48
0.25kW 289rpm BLDC Hub Motor | 0.25kW I 289 RPM I 8.24 Nm I 48 V
The direct drive hub solutions embodying 32 pole and 40 pole rotor structures offer superior torque density with excellent dynamic performance. Explore the limits of challenging applications.- Design opportunities for various voltage level between 24V – 48V
- Low loss density due to concentrated winding arrangement
- Semi-open and closed mechanical options with integrated hall board
- Customized torque-speed characteristics
- Optional coating and mechanical interfaces
0.5kW 623rpm BLDC Hub Motor / EHUB205-70S1K05A1-96
0.5kW 623rpm BLDC Hub Motor | 0.5kW I 623 RPM I 8.42 Nm I 96 V
The direct drive hub solutions embodying 24 pole and 30 pole rotor structures offer superior torque density with excellent dynamic performance. Explore the limits of challenging applications.- Design opportunities for various voltage level between 48V – 96V
- Low loss density due to concentrated winding arrangement
- Semi-open and closed mechanical options with integrated hall board
- Customized torque-speed characteristics
- Optional coating and mechanical interfaces
0.75kW 20krpm PM Synchronous Alternator / EBLA55-25S0K20A0-25
0.75kW I 20 kRPM I 0.4 Nm I 25 V For defense and aerospace applications, obtaining higher power densities from small installation spaces is essential. We offer these alternators for highly responsive and accurate guidance sub-systems.
- Design opportunities for various voltage output between 20V – 100V
- Speed configuration up to 30krpm
- Very low voltage harmonic content due to concentrated winding arrangement
- High torque density due to light weight
- Customized voltage-speed and load characteristics
- Excellent thermal behavior even in harsh environments
1.2kW 992rpm BLDC Hub Motor / EHUB275-57S1K09A1-48
1.2kW 992rpm BLDC Hub Motor | 1.2kW I 992 RPM I 12.42 Nm I 48 V
The direct drive hub solutions embodying 32 pole and 40 pole rotor structures offer superior torque density with excellent dynamic performance. Explore the limits of challenging applications.- Design opportunities for various voltage level between 48V – 96V
- Design flexibility from 250W to 7.5kW
- Low loss density due to concentrated winding arrangement
- Semi-open and closed mechanical options with integrated hall board
- Customized torque-speed characteristics
- Optional coating and mechanical interfaces
1.5kW 15krpm PM Synchronous Alternator / EBLA63-50S0K20A0-60
1.5kW I 15 kRPM I 0.5 Nm I 60 V For defense and aerospace applications, obtaining higher power densities from small installation spaces is essential. We offer these alternators for highly responsive and accurate guidance sub-systems.
- Design opportunities for various voltage output between 20V – 100V
- Speed configuration up to 30krpm
- Very low voltage harmonic content due to concentrated winding arrangement
- High torque density due to light weight
- Customized voltage-speed and load characteristics
- Excellent thermal behavior even in harsh environments
1500W 12083rpm BLDC Motor / EBLM74-122S2K12A2-60
1500W I 12083 RPM I 1.18 Nm I 60 V We combine high torque density with lightweight design and offer compact slotted or slotless structure with 2 pole or 4 pole wiring options
- Available with frameless and hollow-shaft configurations
- Applicable for various voltage requirements between 12V – 120V
- Thermally optimized mechanical design
- Integrated hall board or sensorless options
- Customizable torque-speed characteristics
180W 17082rpm BLDC Motor / EBLM30-70S0K17A0-48
180W I 17082 RPM I 100 mNm I 48 V We combine high torque density with lightweight design and offer compact slotted or slotless structure with 2 pole or 4 pole wiring options
- Available with frameless and hollow-shaft configurations
- Applicable for various voltage requirements between 12V – 120V
- Thermally optimized mechanical design
- Integrated hall board or sensorless options
- Customizable torque-speed characteristics
1kW 774rpm BLDC Hub Motor / EHUB275-57S1K07A1-48
1kW 774rpm BLDC Hub Motor | 1kW I 774 RPM I 12.32 Nm I 48 V
The direct drive hub solutions embodying 32 pole and 40 pole rotor structures offer superior torque density with excellent dynamic performance. Explore the limits of challenging applications.- Design opportunities for various voltage level between 48V – 96V
- Design flexibility from 250W to 7.5kW
- Low loss density due to concentrated winding arrangement
- Semi-open and closed mechanical options with integrated hall board
- Customized torque-speed characteristics
- Optional coating and mechanical interfaces
2.5kW 888rpm BLDC Hub Motor / EHUB275-75S1K08A1-48
2.5kW 888rpm BLDC Hub Motor | 2.5kW I 888 RPM I 26.86 Nm I 96 V
The direct drive hub solutions embodying 32 pole and 40 pole rotor structures offer superior torque density with excellent dynamic performance. Explore the limits of challenging applications.- Design opportunities for various voltage level between 48V – 96V
- Design flexibility from 250W to 7.5kW
- Low loss density due to concentrated winding arrangement
- Semi-open and closed mechanical options with integrated hall board
- Customized torque-speed characteristics
- Optional coating and mechanical interfaces
200W 8677rpm BLDC Motor / EBLM38-66S1K9A0-120
200W I 8677 RPM I 0.33 Nm I 120 V We combine high torque density with lightweight design and offer compact slotted structure with 8 pole wiring
- Available with frameless and hollow-shaft configurations
- Applicable for various voltage requirements between 48V – 120V
- Thermally optimized mechanical design
- Integrated hall board or sensorless options
- Customizable torque-speed characteristics
24V 10A Servo Motor Driver / EDRV-10A12-24V
12-24V I 10 A I 30000 eRPM I +85°C Max Significantly increased servo performance for both BLDC and PMSM motors and wide servo operation capabilities will make you feel reliable at critical applications even in harsh environments.
- Maximum operating voltage up to 28.8VDC
- Configurable sensor inputs (absolute, incremental and hall sensors)
- Thermally optimized mechanical structure
- 3 digital inputs involving high speed option
- Available with totally enclosed and open frame designs
24V 2A Servo Motor Driver / EDRV-2A12-24V
12-24V I 2 A I 30000 eRPM I +85°C Max Significantly increased servo performance for both BLDC and PMSM motors and wide servo operation capabilities will make you feel reliable at critical applications even in harsh environments.
- Maximum operating voltage up to 28.8VDC
- Configurable sensor inputs (absolute, incremental and hall sensors)
- Thermally optimized mechanical structure
- 3 digital inputs involving high speed option
- Available with totally enclosed and open frame designs
